description of parameters vacon • 83
24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com
7
1742 Shaft synchronization control register selection
(2.7.11)
Selector that maps shaft synchronization control register to one process data input
channel. See table 39.
Values:
0 PD0
1 PD1
2 PD2
3 PD3
4 PD4
5 PD5
6 PD6
7 PD7
8 PD8
1750 Master distance
(2.9.1.1)
Number of engineering units [u] corresponding to the number of motor shaft turns
specified by ID1752 and ID1753 for the master drive. Integer part.
1751 MDistFract * 2^16
(2.9.1.2)
Number of engineering units [u] corresponding to the number of motor shaft turns
specified by ID1752 and ID1753 for the master drive. Fractional part x 2
16
.
1752 Master turns
(2.9.1.3)
Number of motor shaft turns corresponding to the distance specified in engineering
units [u] by ID1750 and ID1751 for the master drive. Integer part.
1753 MTurnsFract * 2^16
(2.9.1.4)
Number of motor shaft turns corresponding to the distance specified in engineering
units [u] by ID1750 and ID1751 for the master drive. Fractional part x 2
16
.
1754 Master speed filter TI
(2.9.1.5)
Time constant [s] of the 1st order low-pass filter on master speed measurement.
1757 Follower distance
(2.9.2.1)
Number of engineering units [u] corresponding to the number of motor shaft turns
specified by ID1759 and ID1760 for the follower drive. Integer part.
1758 Follower DistFrac * 2^16
(2.9.2.2)
Number of engineering units [u] corresponding to the number of motor shaft turns
specified by ID1759 and ID1760 for the follower drive. Fractional part x 2
16
.
1759 Follower turns
(2.9.2.3)
Number of motor shaft turns corresponding to the distance specified in engineering
units [u] by ID1757 and ID1758 for the follower drive. Integer part.
1760 Follower TurnsFrac * 2^16
(2.9.2.4)
