USER’S MANUAL__________________________________________________________________
302 _________________________________________________________________ M211322EN-D
0916-134
To compute the noise power in dBm from Words 44 through 47, first
calculate:
from which we obtain:
The four integer values become rather small and severely quantized when
the noise power drops to low values. Historically, these four words were
used to balance the individual gain of the "I" and "Q" channels in the RVP6
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | Range Avg (From LRMSK Command)| Output 40
|_______________________________|_______________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Reserved (Zero) | Output 41
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Reserved (Zero) | Output 42
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Header Config of PROC data (CFGHDR Input #1, Section 6.22) | Output 43
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Noise Sum of I Squared MSB=2**–16 LSB=2**–31 | Output 44
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Noise Sum of I Squared MSB=1 LSB=2**–15 | Output 45
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Noise Sum of Q Squared MSB=2**–16 LSB=2**–31 | Output 46
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Noise Sum of Q Squared MSB=1 LSB=2**–15 | Output 47
|_______________________________________________________________|
