- The Ethernet switch attaches to the RCP903 ASR9-WSP Interface
Panel using: 1 - 223156 Ethernet Cable (Ethernet CAT5E).
- The Ethernet switch attaches to the RVP901-WSP using: 1 - 223156
Ethernet Cable (Ethernet CAT5E).
- The RVP901-WSP attaches to the Interface Panel using: 1 - Vaisala
Cable CBL210313 for Data I/O interface.
- The External 24 volt power supply attaches to the RCP903 ASR9
Interface panel using: 1 - CBL210xxx, a DC power cable with a 9 pin
DB connector.
CBL210313 is an I/O interconnect cable with a 51-pin micro “D”
connector for connecting to the RVP901-WSP. This interconnect cable
will have a standard 62-pin female “D” connector to attach to the Interface
Panel. The standard cable length is 2 m. If the length of the CBL210313
cable needs to be extended, a cable with good isolation between the twisted
signal pairs to maintain signal integrity, guarantee valid logic levels on
TTL signals, and low noise analog signal, will be provided by Vaisala. The
current cable meets the MIL-DTL-22759/11 specification, which is
insulated with PTFE.
CBL210xxx is a DC power cable with a 9 pin “D” connector for
connecting to the Interface panel and an Unmanaged Ethernet Switch. If
the length of the CBL210xxx cable needs to be extended, a cable with good
isolation between the twisted power pairs will be provided by Vaisala.
223156 Ethernet Cable is a CAT5E cable to connect to the Panel via a
network switch or directly from the RVP902 Processor.
G.7.2 RVP901-WSP
The RVP901-WSP is configured with the AC Option and with 2 - 30 MHz
Filters specified.
Table 36 RVP901-WSP Interface to ASR9 Radar
Signal RVP901-WSP Connector
COHO J7
COHO J13E
IF J13A (31.07 MHz)
Table 37 RVP901-WSP SMA Connector Summary
J-ID Label Type Description Use
J7 CLK IN SMA Reference Clock Input Y
J8 TRIG-B SMA General purpose trigger I/O N
J9 CLK OUT SMA Reference Clock Output N
J10 DDS SMA Direct Digital Synthesizer output N
