USER’S MANUAL__________________________________________________________________
496 _________________________________________________________________ M211322EN-D
G.7.10 J6, RVP901-WSP Misc IO A to
RCP903 ASR9-WSP Panel
Table 46 CBL210313 RCP903 INTERCONNECT CABLE TO
RVP901-WSP MISC IO PORT A (J3)
Table 45 RVP900 SIGNAL TYPES IN CBL210313
Type Destination
GPDIFF_PIN_LP/N RS-422 signals
TTLIO_PIN/GND TTL signals
AMUX_P0/AMUX_N0 Differential analog input A/D signals
+5V +5VDC
-5V -5VDC
Gnd Ground
