Vaisala RVP900

Appendix F ___________________________________________________ RCP902 WSR98D Panel
VAISALA______________________________________________________________________ 465
F.7.7 J11 - RF Test Switch (RF-TEST SW)
Connector Type: DB15S
Description: Controls the 10-position RF test switch.
F.7.8 J12 - DAU Serial I/O (SERIAL-IN)
Connector Type: DB15P
Description: DAU serial line from the 98D.
9NC
Signal Connections Initial Condition
1 DRSIGBIT_N4 H
2 DRSIGBIT_P4 L
3 DRSIGBIT_N3 H
4 DRSIGBIT_P3 L
5 DRSIGBIT_N2 H
6 DRSIGBIT_P2 L
7 DRSIGBIT_N1 H
8 DRSIGBIT_P1 L
9NC
10 NC
11 NC
12 GND
13 GND
14 NC
15 NC
Signal Connections Initial Condition
1NC
2NC
3NC
4NC
5NC
6NC
7NC
8NC
9NC
10 NC
11 DAU_TX
12 NC
Signal Connections Initial Condition
