Appendix F ___________________________________________________ RCP902 WSR98D Panel
VAISALA______________________________________________________________________ 469
For more information, refer to drawing DRW240510.
F.8.1 RCP902 WSR98D I/O Interconnect
Breakout
The interconnect cables breakout each of the 51-pin micro "D" connectors
on the IFDR into standard 62-pin female "D" connectors to the RCP902
WSR98D panel. Table 31 and Table 32 provide the cable wiring and
internal signal names on the IFDR and WSR98D. The standard cable
length is 2 m.
If extending the length of this interface by additional cabling, a cable with
good isolation between the twisted signal pairs is required to maintain the
signal integrity, guarantee valid logic levels on TTL signals, and low noise
on analog signals. The Vaisala provided wire meets the MIL-DTL-
22759/11 specification, which is insulated with PTFE. If additional
shielding between wire pairs is feasible it should also be considered.
Table 31 RCP902 WSR98D Interconnect Cable for Misc I/O A
Connection
IFDR
J6 - 51 Pin
IFDR Signal Name WSR98D
J1 - 62 Pin
WSR98D Signal Name
1/19 GPDIFF_PIN_LP/N0 1/23 TRIGGER_CHARGE_TRG_P/
N
2/20 GPDIFF_PIN_LP/N1 2/24 MOD_DISCHARGE_TRG_P/N
3/21 GPDIFF_PIN_LP/N2 3/25 MOD_CHARGE_TRG_P/N
4/22 GPDIFF_PIN_LP/N3 4/26 POST_CHARGE_TRG_P/N
5/23 GPDIFF_PIN_LP/N4 5/27 FILAMENT_RESET_TRG_P/N
6/24 GPDIFF_PIN_LP/N5 6/28 RF_DRIVE_TRG_P/N
7/25 GPDIFF_PIN_LP/N6 7/29 RF_PULSE_START_TRG_P/N
8/26 GPDIFF_PIN_LP/N7 8/30 RCVR_PROTECT_CMD_P/N
9/27 GPDIFF_PIN_LP/N8 9/31 RCVR_PROTECT_RSP_P/N
10/28 GPDIFF_PIN_LP/N9 10/32 RVP_UP_RSP_P/N
11/29 TTLIO_PIN0/GND 11/33 CONN_LED_LO
12/30 TTLIO_PIN1/GND 12/34 SPARE_TTL11
13/31 TTLIO_PIN2/GND 13/35 SPARE_TTL12
14/32 TTLIO_PIN3/GND 14/36 SPARE_TTL13
15/33 TTLIO_PIN4/GND 15/37 SHORT_RF_PULSE_SEL
16/34 TTLIO_PIN5/GND 16/38 SHORT_BEAM_PULSE_SEL
17/35 TTLIO_PIN6/GND 17/39 RVP_TP1
18 GND 22
36/37 TTLIO_PIN7/GND 18/40 RVP_TP2
38/39 TTLIO_PIN8/GND 19/41 NC
40/41 TTLIO_PIN9/GND 20/42 NC
42/43 AMUX_P0/AMUX_N0 54/55 AMUX_5V
44/45 V_5P0/GND +5V 47/48 J1 OK LED
