Vaisala RVP900

USER’S MANUAL__________________________________________________________________
470 _________________________________________________________________ M211322EN-D
46/47 AMUX_P1/AMUX_N1 57/58 SPARE_AMUX_P/N
48/49 V_N5P0/GND -5V 49/50 NC
50/21 AMUX_P2/AMUX_N2 60/61 NC
Table 32 RCP902 WSR98D Interconnect Cable for Misc I/O B
Connection
IFDR
J3 - 51 Pin
IFDR Signal Name WSR98D
J2 - 62 Pin
WSR98D Signal Name
1/19 GPDIFF_PIN_LP/N10 1/23 PHCOHOSEL_P/N
2/20 GPDIFF_PIN_LP/N11 2/24 RFGATE_P/N
3/21 GPDIFF_PIN_LP/N12 3/25 RVP_UP_CLK_P/N
4/22 GPDIFF_PIN_LP/N13 4/26 RVP_UP_DATA_P/N
5/23 GPDIFF_PIN_LP/N14 5/27 RVP_UP_TIME1_P/N
6/24 GPDIFF_PIN_LP/N15 6/28 RVP_UP_TIME2_P/N
7/25 GPDIFF_PIN_LP/N16 7/29 RVP_UP_SEL_P/N
8/26 GPDIFF_PIN_LP/N17 8/30 RVP_UP_SPARE_P/N
9/27 GPDIFF_PIN_LP/N18 9/31 RCP_TP1_P/N
10/28 GPDIFF_PIN_LP/N19 10/32 RCP_TP2_P/N
11/29 TTLIO_PIN0/GND 11/33 CHANFAIL
12/30 TTLIO_PIN1/GND 12/34 OPFREQREFFL
13/31 TTLIO_PIN2/GND 13/35 COHOREFFAIL
14/32 TTLIO_PIN3/GND 14/36 PHMODFAIL
15/33 TTLIO_PIN4/GND 15/37 DRSIGBIT1
16/34 TTLIO_PIN5/GND 16/38 DRSIGBIT2
17/35 TTLIO_PIN6/GND 17/39 DRSIGBIT3
18 GND 22
36/37 TTLIO_PIN7/GND 18/40 DRSIGBIT4
38/39 TTLIO_PIN8/GND 19/41 CONN_LED_LO
40/41 TTLIO_PIN9/GND 20/42 NC
42/43 AMUX_P0/AMUX_N0 54/55 LOG_VIDEO_P/N
44/45 V_5P0/GND +5V 47/48 J2 OK LED
46/47 AMUX_P1/AMUX_N1 57/58 NC
48/49 V_N5P0/GND -5V 49/50 NC
50/21 AMUX_P2/AMUX_N2 60/61 NC
Table 31 RCP902 WSR98D Interconnect Cable for Misc I/O A
Connection
IFDR
J6 - 51 Pin
IFDR Signal Name WSR98D
J1 - 62 Pin
WSR98D Signal Name
