Chapter 7 __________________________________________________ Host Computer Commands
VAISALA______________________________________________________________________ 319
0916-162
PLT Indicates that a scope plot is being drawn now.
The 2-bit intensities of each of 16 possible strokes of data is given in the
following 4-word sequence. An intensity of zero represents "OFF"; one,
two and three are successively brighter.
0916-163
The data for each stroke of the plot is given by the following sequence of
501 words.
0916-164
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 0 1 | 0 0 0 0 | Int 3 | Int 2 | Int 1 | Int 0 |
|_______________|_______________|_______|_______|_______|_______|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 0 1 | 0 0 0 1 | Int 7 | Int 6 | Int 5 | Int 4 |
|_______________|_______________|_______|_______|_______|_______|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 0 1 | 0 0 1 0 | Int 11| Int 10| Int 9 | Int 8 |
|_______________|_______________|_______|_______|_______|_______|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 0 1 | 0 0 1 1 | Int 15| Int14 | Int 13| Int 12|
|_______________|_______________|_______|_______|_______|_______|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 1 0 | | Stroke Number | Plot Data
|_______________|_______________________________|_______________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 1 1 | Value to Plot (0 – 4095) | Word #1
|_______________|_______________________________________________|
.
.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| 1 0 1 1 | Value to Plot (0 – 4095) | Word #500
|_______________|_______________________________________________|
