15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | 0 0 0 1 0 1 0 1 1 1 1 1 | Command
|_______________|_______________________________________________|
The first three words supply a mask that indicates which data types are being set:
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | Z | T | V | W |ZDR| |KDP| | Input 1
|___|___|___|___|___|___|_______|___|___________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | (Tx Vert) | (Tx Horz) | | | |
| |Flg|Phi Rho Ldr|Phi Rho Ldr|SQI|RHV|PDP| Input 2
|_______________________|___|___|___|___|___|___|___|___|___|___|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| <all spares> | Input 3
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| LOG Threshold in 1/16 of dB (SOPRM Input 4) | Input 4
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| CCOR Threshold in 1/16 of dB (SOPRM Input 5) | Input 5
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | SQI Threshold (SOPRM Input 6) | Input 6
|_______________________________|_______________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Weather Signal Power Threshold in 1/16 of dB (SOPRM Input 7) | Input 7
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Threshold Control Flags (SOPRM Input 11,12,13,14,19) | Input 8
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| <spare> | Input 9
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| <spare> | Input 10
|_______________________________________________________________|
