USER’S MANUAL__________________________________________________________________
336 _________________________________________________________________ M211322EN-D
The target simulator can be used with both live and simulated (I,Q) data
(See LSIMUL opcode in Section 7.10 Load Simulated Time Series Data
(LSIMUL) on page 304). In the former case, it allows you to overlay
simulated physical targets on top of real physical targets from the radar
receiver.
0916-184
0916-185
0916-186
Oper=0 Disable all target simulation activity (no additional args)
Oper=1 Enable simulation of all defined targets (no additional args)
Oper=2 Define a new simulated target (arg list follows)
Targ Targ Which target is being defined
Co/Cx Place simulated target in Co-Pol and/or Cross-Pol Rx
channels
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | Oper | 0 0 0 1 1 0 1 1 1 1 1 1 | Command
|_______|_______|_______________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| | Co| Cx| | Targ | Input 1
|_______________________________|___|___|_______________|_______|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Target Starting Range in Tenths of Kilometers | Input 2
|_______________________________________________________________|
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
| | | | | | | | | | | | | | | | |
| Target Length in Tenths of Kilometers | Input 3
|_______________________________________________________________|
