2 Local panel user interface
Operation and configuration
instructions
VAMP 24h support phone +358 (0)20 753 3264
Total harmonic distortion of phase
current I’L2 [%]
Total harmonic distortion of phase
current I’L3 [%]
Harmonics of phase current IL1 [%]
(see Figure 2.3.2-1)
Harmonics of phase current IL2 [%]
(see Figure 2.3.2-1)
Harmonics of phase current IL3 [%]
(see Figure 2.3.2-1)
Harmonics of phase current I’L1 [%]
(see Figure 2.3.2-1)
Harmonics of phase current I’L2 [%]
(see Figure 2.3.2-1)
Harmonics of phase current I’L3 [%]
(see Figure 2.3.2-1)
Figure 2.3.2-1. Example of harmonics bar display
