Engineer programming via the keypad
16
X-BUS
125
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Name
Description
 Unset
 Partset A
 Partset B
 Fullset
 Toggle Unset/Fullset
 Toggle Unset/Partset A
 Toggle Unset/Partset B
 All Okay
 Setting Authorisation
VISUAL INDICATIONS
(Flexible Mode only)
Enables you to assign specific behaviour to each LED on the
indicator module. Each of the LEDs has the following options:
 FUNCTION — the following options are available:
– KEYSWITCH — select a keyswitch and the position
of the key.
– DISABLED — select to disable the LED.
– SYSTEM — select the alarm type which triggers the
LED.
– AREA — select the area which triggers the LED.
– ZONE — select the zone which triggers the LED
– DOOR — select the door and the door option which
triggers the LED.
 ON – COLOR — specify the activation colour
 ON – FLASH — specify the behaviour of the LED in
active state. Available options are:
– Permanent — always on.
– Flash Fast\Medium\Slow — varying speed of the
flashing.
 OFF – COLOR — specify the deactivation colour.
 OFF – FLASH — specify the behaviour of the LED in the
inactive state. Available options are:
– Permanent — always on.
– Flash Fast\Medium\Slow — varying speed of the
flashing.
LED ALWAYS
Enable if LED indicators remain active when keys are
deactivated.
AUDIBLE IND.
(Flexible Mode only)
Select the audible indicators for alarms, entry/exit, and
keypresses,
DEACTIVATION
(Flexible Mode only)
Choose one, or more, of the following deactivation options:
 Calendar – select a calendar from the available options.
 Keyswitch – select a keyswitch from the available
options.
 Keypad - select a keypad from the available options.
 Card Reader – enable or disable deactivation using a
keypad.
MODE
Select Linked or Flexible. Linked mode reduces the number
of options available in the Expander Edit menu.
INPUT
Select the zone
