Vanderbilt SPC6350 User Manual

Engineer programming via the browser
17
Configuring Communications
281
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Non-active ATP Connection
Select the ATP connection type when the
ATP is operating as a backup
communication path.
 Permanent: Stay Connected
 Temporary: Hangup 1second
 Temporary: Hangup 20 seconds
 Temporary: Hangup 80 seconds
 Temporary: Hangup 3 minutes
 Temporary: Hangup 10 minutes
 Temporary: Hangup 30 minutes
Test Calls
Test Call Mode (Non Active ATP)
Select the mode for sending test calls when
the ATP is the non-active ATP.
 Test calls Disabled
 Test call every 10 minutes
 Test call every 1 hour
 Test call every 4 hours
 Test call every 24 hours
 Test call every 48 hours
 Test call every 7 days
 Test call every 30 days
Test Call Mode (Active ATP)
Select the mode for sending test calls when
the ATP is the active ATP.
 Test calls Disabled
 Test call every 10 minutes
 Test call every 1 hour
 Test call every 4 hours
 Test call every 24 hours
 Test call every 48 hours
 Test call every 7 days
Test call every 30 days
Encryption (256-bit AES with CBC)
Encryption Key Mode
Select how the encryption gets updated.
 Auto Encryption
 Auto Encryption with Updates
 Fixed Encryption
Note: Auto Encryption uses the default key
and updates it once. Auto Encryption with
Updates changes the encryption key every
50,000 messages or once per week,
whichever comes first.
Encryption Password
Optional password used to provide
increased security during initial ATP
commissioning. The password must be
entered at the SPT or RCT independently.
Reset Encryption
Reset the Encryption Key and password to
the default values.
ATP Profiles
Event Profile
Select the Event Profile which defines how
and which events are transmitted on this
ATS.
 Use ATS Setting
 Default Event Profile
 All events
