Appendix
23
SI
A Codes
341
Vanderbilt
Installation & Co
nfiguration Manu
al
A6V10276959
01.05.2016
DESCRIPTION
CODE
ENET PANIC RESTORAL
PR
USER PANIC ALARM
PA
ENET FIRE ALARM
FA
ENET FIRE RESTORAL
FR
ENET MEDICAL ALARM
MA
ENET MEDICAL RESTORAL
MR
MDT PANIC
PA
MDT TILT
MA
MDT BELT CLIP
HA
MDT PANIC RESTORE
PR
MDT TILT RESTORE
MR
MDT BELT CLIP RESTORE
HR
RPA PANIC
PA
RPA PANIC RESTORE
PR
RPA HOLDUP
HA
RPA HOLDUP RESTORE
HR
USER CODE CHANGE
JV
CODE DELETED
NON-STANDARD SIA CODES FOR ZONE STATE REPORTING
ZONE OPEN
ZO
ZONE CLOSE
ZC
ZONE SHORT
ZX
ZONE DISCON
ZD
ZONE MASKED
ZM
ZONE WALKED
TP
WALKTEST START
ZK
WALKTEST END
TC
ZONE LOW BATT
XT
ZONE LOW BATTERY RESTORAL
XR
OTHER NON-STANDARD SIA CODES
CAMERA ONLINE
CU
CAMERA OFFLINE
CV
ALERT CLOSE
SD
ALERT REOPEN
SO
XBUS ALERT CLOSE
NB
XBUS ALERT REOPEN
NO
UNKNOWN CARD
AU
USER ACCESSING
JP
USER ACCESSING END
ZG
LOW VOLTAGE
XD
LOW VOLTAGE RESTORAL
XG
340
