Vanderbilt SPC6350 User Manual

4
Technical Data
SPC6000
36
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
Electronic Outputs
 SP6320\6330 — 5 outputs:
– 2 internal/external bells
– 3 programmable. Maximum 400 mA resistive
switching current per output, supplied by auxiliary
output.
 SPC6350 — 8 outputs. Maximum 400mA resistive
switching current per output
– 5 standard power outputs
– 3 supervised outputs
Firmware
V3.x
Door capacity
Max. 64 entry doors or 32 entry/exit doors
Number of card reader
Max. 64
Radio module
Optional (SPCW110)
Verification
32 verification zones with max. 4 IP-cameras and 32 audio
devices.
Video
Up to 16 pre / 16 post event images (by JPEG resolution
320 x 240, max. 1 frame / sec.)
Audio
Up to 60 sec. pre / 60 sec. post audio recording
Field bus 1)
X-BUS on RS-485 (307 kb/s)
Number of field devices 2)
Max. 128 (32 keypads, 32 door-expanders, 64 input/output
expanders)
Connectable field devices
 Keypads: SPCK42x, SPCK62x
 Door expanders: SPCA210, SPCP43x
 Expanders with I/O: SPCE65x, SPCE45x, SPCP33x,
SPCP35x, SPCE110, SPCE120, SPCV32x
Interfaces
 2 X-BUS (2 spurs or 1 loop),
 2 RS232
 1 USB (PC connection),
 1 SPC Fast Programmer,
 SPC63xx: Additionally 1 Ethernet (RJ45)
Tamper contact
 SPC6330: Front spring tamper, 2 auxiliary tamper
contact inputs
 SPC6350: Front/back tamper switch
Power supply
Type A (per EN50131-1)
Mains voltage
230 V AC, + 10%/ -15%, 50 Hz
Mains fuse
 SPC6330 : 250 mA T (replaceable part on mains
terminal block)
 SPC6350 : 800mA T (replaceable part on mains
terminal block)
Power consumption
 SPC6330: Max. 200 mA at 230 V AC
 SPC6350: Max. 500mA at 230 V AC
Operating current
 SPC6330: Max. 200 mA at 12 V DC
 SPC6350: Max. 210 mA at 12 V DC
Quiescent current
SPC63xx Controller: Max. 170 mA at 12 V DC (195 mA with
PSTN, 300 mA with GSM, 325 mA with PSTN & GSM)
