Vanderbilt SPC6350 User Manual

Wiring the system
10
Wiring the zone inputs
85
Vanderbilt
Installation & Configuration Manual
A6V10276959
01.05.2016
(-30%)
(+30%)
SINGLE_1K5
1.1kΩ
(-27%)
1.5kΩ
2.1kΩ
(+40%)
23kΩ
N/A
Infinite
SINGLE_2K2
1.6kΩ
(-28%)
2.2kΩ
2.9kΩ
(+32%)
23kΩ
N/A
Infinite
SINGLE_4K7
3.1kΩ
(-22%)
4.7kΩ
6.3kΩ
(+24%)
23kΩ
N/A
Infinite
SINGLE_10K
7kΩ
(-30%)
10kΩ
13kΩ
(+30%)
23kΩ
N/A
Infinite
SINGLE_12K
8.5kΩ
(-30%)
12kΩ
15.5kΩ
(+30%)
23kΩ
N/A
Infinite
Dual EOLs with PIR Masking and Fault
EOL Type
Quiescent
Alarm
Min
Nom
Max
Min
Nom
Max
Mask_1K_1K_6K8
(1K / 1K / 6K8)
700Ω
(-30%)
1kΩ
1.3kΩ
(+30%)
1.5kΩ
(-25%)
2kΩ
2.5kΩ
(+25%)
Mask_1K_1K_2K2
(1K / 1K / 2K2)
700Ω
(-30%)
1kΩ
1.3kΩ
(+30%)
1.5kΩ
(-25%)
2kΩ
2.6kΩ
(+30%)
Mask_4K7_4K7_2K2
(4K7 / 4K7 / 2K2)
3.9kΩ
(-18%)
4.7kΩ
5.6kΩ
(+20%)
8.4kΩ
(-11%)
9.4kΩ
10.3kΩ
(+10%)
EOL Type
Fault
Masking
Min
Nom
Max
Min
Nom
Max
Mask_1K_1K_6K8
2700Ω
(-69%)
8.8kΩ
12.6kΩ
(+20%)
-
-
-
Mask_1K_1K_2K2
2.8k
(-13%)
3.2k
3.6k
(+13%)
3.8k
(-10%)
4.2k
4.8k
(+15)
Mask_4K7_4K7_2K2
6k
(-14%)
6.9k
7.8k
(+14%)
10.8k
(-7%)
11.6k
12.6k
(+9%)
Dual EOLs
EOL Type
Quiescent
Alarm
Min
Nom
Max
Min
Nom
Max
DUAL_1K0_470
400Ω
(-20%)
470Ω
700kΩ
(+40%)
1.1kΩ
(-27%)
1.5kΩ
2kΩ
(+34%)
DUAL_1K0_1K0
700Ω
(-30%)
1kΩ
1.3kΩ
(+30%)
1.5kΩ
(-25%)
2kΩ
2.6kΩ
(+30%)
DUAL_1k0_2k2
1.6kΩ
(-28%)
2.2kΩ
2.9kΩ
(+32%)
2.3kΩ
(-29%)
3.2kΩ
4.2kΩ
(+32%)
DUAL_1k5_2k2
1.6kΩ
(-28%)
2.2kΩ
2.9kΩ
(+32%)
2.7kΩ
(-28%)
3.7kΩ
4.8kΩ
(+30%)
DUAL_2K2_2K2
1.6kΩ
(-28%)
2.2kΩ
2.9kΩ
(+32%)
3.4kΩ
(-23%)
4.4kΩ
5.6kΩ
(+28%)
DUAL_2k2_4k7
4.1kΩ
(-13%)
4.7kΩ
5.4kΩ
(+15%)
6kΩ
(-14%)
6.9kΩ
7.9kΩ
(+15%)
DUAL_2K7_8K2
7.2 kΩ
(-13%)
8.2kΩ
9.2kΩ
(+13%)
9.9kΩ
(-10%)
10.9kΩ
11.9kΩ
(+10%)
DUAL_3K0_3K0
2.1kΩ
3.0kΩ
3.9kΩ
4.5kΩ
6kΩ
7.5kΩ
