SPECIFICATIONS
Engine Specifications - 610000
ENGINE 6114, 6134-37 6132-3 61H 61A 61E 61G
Fuel Type and System Gasoline -
Carburetor
Gaseous - Mixer Gaseous - Mixer Gasoline - EFI-ETC Gasoline - EFI Gasoline - EFI-ETC
Bore 3.366 in (85.5 mm)
Stroke 3.405 in (86.5 mm)
Displacement 60.6 ci (993 cc)
Compression Ratio 8.2:1 8.5:1 or 9.7:1 8.2:1 8.5:1
With Crankcase Cover Silicone Sealant Bead: 0.004-0.017 in (0.009-0.44 mm)Crankshaft End Play
With Crankcase Cover Steel Core Gasket: 0.015-0.039 in (0.39-1.00 mm)
Oil Capacity 78-80 oz (2.3-2.4 L)
Oil Capacity
- Oil Guard
6137 - 160
oz (4.7 L)
61A6 - 160
oz (4.7 L)
61E8/9 - 160
oz (4.7 L)
61G9 - 160
oz (4.7 L)
Armature Air Gap 0.005-0.012 in (0.13-0.30 mm)
CKP Sensor Air Gap 0.010 in (0.25 mm)
Spark Plug Gap 0.030 in
(0.076 mm)
0.020 in (0.51 mm) 0.030 in (0.076 mm)
Valve Clearance
- Intake
0.004-0.006 in (0.10-0.15 mm)
Valve Clearance
- Exhaust
0.007-0.009 in (0.18-0.23 mm)
Crankcase
MAG Bearing
Oil Seal Depth
Flush to 0.040 in (0-1.0 mm)
Crankcase Cover
PTO Bearing
Oil Seal Depth
0.040-0.080 in (1.0-2.0 mm)
Engine Specifications - 540000
ENGINE 5404 5414-17, 5124-27 5434-37 54E1 54E6
Fuel Type and System Gasoline - Carburetor Gasoline - EFI
Bore 3.37 in (85.6 mm)
Stroke 3.07 (77.98 mm)
Displacement 54.7 ci (896 cc)
Compression Ratio 8.2:1
With Crankcase Cover Silicone Sealant Bead: 0.004-0.017 in (0.09-0.44 mm)Crankshaft End Play
With Crankcase Cover Steel Core Gasket: 0.015-0.039 in (0.39-1.00 mm)
Oil Capacity 78-80 oz (2.3-2.4 L)
Oil Capacity - Oil Guard 5417 - 160 oz (4.7 L) 5437 - 160 oz (4.7 L) 160 oz (4.7 L)
Armature Air Gap 0.005-0.012 in (0.13-0.30 mm)
CKP Sensor 0.010 in (0.25 mm)
Spark Plug Gap 0.030 in (0.76 mm)
Valve Clearance
- Intake
0.004-0.006 in (0.10-0.15 mm)
Valve Clearance
- Exhaust
0.007-0.009 in (0.18-0.23 mm)
Crankcase MAG
Bearing Oil Seal Depth
Flush to 0.040 in (0-1.0 mm)
Crankcase Cover PTO
Bearing oil Seal Depth
0.040-0.080 in (1.0-2.0 mm)
164 vanguardpower.com
