Air Block Plate, Valley Air Guides, Speed Control
Bracket
1. Remove the2 valley air block plate mounting fasteners
(A, Figure 87).
87
2. Remove the valley air block plate from the engine and
set aside.
3. Remove the 4 valley air guide fasteners (A, Figure 88).
88
NOTE: Your engine may be equipped with an air filter
support bracket ora speed control bracket. These brackets
utilize the valley air guide fasteners to attach to the
engine.See Figure 89 for engines equipped with the low-
profile air cleaner support bracket, and see Figure 90 for
engines equipped with the speed control bracket.
89
90
78 vanguardpower.com
