FASTENER TORQUE
Starter Solenoid Rotor Brush Strap
Nut
87 lb-in (9.8 Nm)
Stud/Plate to Fuse Block Bracket 12 lb-in (1.4 Nm)
Throttle Body Collar Studs 95 lb-in (10.7 Nm)
Throttle Control to Mounting
Bracket Screws
35 lb-in (4 Nm)
Throttle Cable Clamp to Speed
Control Bracket Screw
23 lb-in (2.6 Nm)
Throttle Lever - Rotary Style - to
Throttle Shaft Bolt
90 lb-in (10.2 Nm)
Valley Air Block Plate toCrankcase 18 lb-in (2 Nm)
Valve CoverBolt 70 lb-in (7.9 Nm)
Valve Cover Breather Screw -
Small 2 Bolt Design
43 lb-in (4.8 Nm)
FASTENER TORQUE
Valve Cover Breather Screw -
Large 4 Bolt Design
87 lb-in (9.8 Nm)
Wire Guard to Coupling Nut 90 lb-in (10.2 Nm)
Wire Harness Clip to Lift Bracket
Screw
33 lb-in (3.7 Nm)
Wire Harness Ground
toCrankcase
18 lb-in (2 Nm)
Wire Harness/ Fuel Hose Clamp 90 lb-in (10.2 Nm)
Wire Harness Ground to Throttle 18 lb-in (2 Nm)
Wire Harness Clamp to Intake
ManifoldScrew
90 lb-in (10.2 Nm)
167
