3.8. Slice Thickness Evaluation
3.8.1. Slice Thickness Standard
Parameter LSL (Lower Specification Limit) USL (Upper Specification Limit)
Slice Thickness 38.0 mm 42.0 mm
3.8.2. Phantom Specification
QUART: DVT Phantom
3.8.3. Test Method
1. Open the CT_DVT Phantom image captured in Section 1.3 through the 3D Viewer
2. Measure the length of the phantom in the Sagittal view.
3.8.4. Test Result
Parameter LSL Measurement value USL Pass/Fail
Slice Thickness 38.0 mm 42.0 mm
