2.4. CT Bad Pixel Verification
2.4.1. Bad pixel definition
• Dead pixel: no responsive pixel (value : 0 or 16384)
• Non-uniform response pixel: Pixels with ±30% response deviation from neighboring pixels
2.4.2. Bad line definition
Bad pixels over 50% of effective area width and height are defined as bad lines
When it is an effective area of M x N,
1 x M or N x 1 or more is defined as a bad line
Total max. 7 line
There should be at least 5 lines of normal pixels between bad and bad lines.
2.4.3. Cluster definition
Continuous bad pixels with 3 x 3 or more continuous . (Single bad pixel is surrounded by bad
pixels in all directions (up/down/left/right/diagonal))
