Page 72 of 244
2.4.4. Bad Pixel Verification
To verify bad pixels:
1. Run the VAKCAP.exe file.
2. Select Soft Calib.
3. Click the V button to open the View16 program.
VAKCAP.exe file Path :
C:\VCaptureSW\Acquisition\CT\WidePANO.
4. Select S from the M box and click the 184x686BPM.raw from the raw file list
5. Examine the sensor effective area to check if there is a bad pixel of a bad line.
