Page 172 of 244
6.1.7. Bad Pixel Definition and Specifications
6.1.7.1 Bad pixel definition
Dead pixel: no responsive pixel (value : 0 or 16384)
Non-uniform response pixel: Pixel that shows a ±30% response deviation from
neighboring pixels.
6.1.7.2 Bad line definition
Bad pixels over 50% of effective area width and height are defined as bad lines
When having an effective area of M x N, 1 x M or N x 1 or more is defined as a bad
line
Total max. 7 line
There should be at least 5 lines of normal pixels between bad lines.
6.1.7.3 Cluster definition
Continuous bad pixels with 3 x 3 or more in a row (single bad pixels are surrounded by
bad pixels in all directions (up/down/left/right/diagonal))
