Page 19 of 244
1.2.3.1 Sensor Interface (SUB056)
Function Control Signal Interfacing of
: Sensor moving motor, Rotator motor, and the Sensor
Control Power Interfacing of Sensor
1.2.3.2 Inverter
Function
Supply High DC/AC Power
