5. Installing the Equipment: Wall Mount
72 Green 16/18 Installation Manual
5.1.3 Combining the Equipment with the Anchor Bolts
1. Put the aligning plate on the floor while making sure that the aligned plate’s
holes engage in the anchored bolts.
2. Put the equipment in a vertical position slowly while holding the upper handle, as
shown in the figure.
Be careful not to damage the cables before erecting the
equipment. Keep them clear of
the equipment.
