5. Installing the Equipment: Wall Mount
Smart Plus (PHT-35LHS) Installation Manual 67
Combining the Equipment with the Anchor Bolts
1. Put the aligning plate on the floor and ensure that all anchored bolts come
through the holes on the plate.
2. Put the equipment in a vertical position slowly while holding the upper handle as
shown in the figure.
Be careful not to damage the cables before erecting the
equipment. Keep them clear of
the equipment.
To Next Page
