11
EMR
3
- Truck Installations
EMR4 Truck Installation Installation Procedures - Fuel Oil Truck Application
TOKHEIM, DANIELS & DONOVAN FLOW METER INSTALLATION
Table 3 lists the parts included in the EMR4 approved kit. In addition to the “Installation Procedure” on page 6, see
Figure 7 on page 12, Figure 8 on page 13, and Figure 9 on page 14 for instructions on how to disassemble then
reassemble the calibrator.
Run the flow meter and verify that the flow meter’s vertical drive shaft (Figure 7) is rotating in a counter clockwise
direction. If possible, make the necessary mechanical adjustment(s) to ensure the vertical drive shaft rotates
counter-clockwise.
Table 3. Display Head-to-Tokheim, Daniels & Donovan Adapter Kit 845900-004
Item Qty V-R P/N
Washer - 0.258” x 0.010” x 0.500” 2 011071-325
Wire - Sealing 24” Lg 1 011853-285
Coupling - Slot 0.156” W 1 065004-010
Screw - 1/4-28 x 0.62” Hex 4 503615-001
Lockwasher - 0.256” x 0.02” 4 510003-006
Groove Pin - 0.125” D x 0.750” 1 510105-140
Groove Pin - 0.063” D x 0.781” 1 510105-177
Retaining Ring 2 511810-001
Group - Adapter Shaft 1 331431-001
