Veeder-Root EMR4 Application Guide

15
EMR
3
- Truck Installations
EMR4 Truck Installation Installation Procedures - Fuel Oil Truck Application
SMITH FLOW METER INSTALLATION
Table 4 lists the parts included in the EMR4 approved adapter kit. In addition to “Installation Procedure” on
page 6, see Figure 10 on page 16, Figure 11 and Figure 12 on page 17, and Figure 13 on page 18 for
instructions on how to disassemble then reassemble the calibrator.
Table 4. Display Head-to-Smith Meter Adapter Kit 845900-005
Item Qty V-R P/N
Wire - Sealing 24” LG 1 011853-285
Coupling - Slot 0.130” W 1 065004-005
Screw - 1/4-28 x 0.62 Hex 4 503615-001
Lockwasher - 0.256” x 0.02” 4 510003-006
Groove Pin - 0.078” D x 0.562” 1 510114-001
Groove Pin - 0.063” D x 0.781” 1 510105-177
Group - Short Shaft 1 331433-001
Group - Long Shaft 1 331433-002
Coupling 1 068845-005
