Veeder-Root EMR4 Application Guide

A-3
Appendix A: EMR4 Safety Instructions & System Specifications EMR4 System Specifications
Check that the mounting surface material is strong enough to support the EMR4 IB.
If the EMR4 IB requires cleaning, do not use any liquid materials (e.g. cleaning solvents). It
is recommended that the unit be wiped with a clean dry cloth when necessary.
Overall dimensions and the weight of the various system components are as shown in Table A-1 and Table A-2:
To allow for maintenance ensure that the
EMR4 IB is in an accessible area, even when the unit’s doors are open.
Ensure that all relevant subcontractors and other personnel are aware of the selected location.
Table A-1. System Component Information
System
Operating
Temperature
Range
Height Width Depth Weight
Descriptive
System
Document
EMR4 IB
-25°<
Ta < 40°C 254mm
(10 in.)
215.9mm (8.5 in.) 80.9mm
(3.185
in.)
7.6 lbs
(3430 g)
331940-022
EMR4 Display Head
-40°<
Ta < 60°C 129.6mm
(5.1 in.)
241.3mm (9.5 in.) -
w/o optional keypad
330.2mm (13 in.) -
w/optional keypad
215.9mm
(8.5 in.)
11 lbs
(4990 g)
Optional Keypad
-40°<
Ta < 60°C 117mm
(4.6 in.)
92mm (3.6 in.) 59mm
(2.3 in.)
1 lb
(454 g)
Table A-2. Remote Pulser Information
Operating
Temperature
Range
Shaft
Length
Shaft
Diameter
Housing
Diameter
Housing
Depth
Weight
Descriptive
System
Document
-25°<
Ta < 70°C
(-13°< Ta < 158°F)
11.5mm
(0.45 in.)
6.4mm
(0.250 in.)
101.6mm (4 in.) 62mm
(2.44 in.)
1.4 lbs
(652 g)
331940-022
NOTICE
