EMR4 Truck Installation Neptune Flow Meter Installation
Neptune Flow Meter Installation
Follow the installation procedures for your particular EMR4 approved Flow Meter Installation.
NEPTUNE FLOW METER WITH TEMPERATURE COMPENSATION
NEPTUNE FLOW METER WITHOUT TEMPERATURE COMPENSATION
Table 5. Display Head-to-Neptune With Temp. Comp. Adapter Kit 845900-008
Item Qty V-R P/N
Neptune Adapter Ring 1 333746-001
Input Shaft 1 331656-001
Screws - 1/4-20 x 3/4” 4 510500-325
Screws - 1/4-20 x 5/8” 4 503615-001
Seal Wire 1 011853-285
Groove Pin 1 510107-002
Lockwashers 8 510003-006
Washer - 0.010” thick 1 011071-929
Washer - 0.005” thick 1 011071-785
Truarc Retaining Ring 1 511816-001
Coupling 1 323372-001
Table 6. Display Head-to-Neptune W/o Temp. Compensation Adapter Kit 845900-009
Item Qty V-R P/N
Neptune Spacer 1 323672-002
Stud 2 036788-005
Lockwasher 2 510023-001
Nut 2 511041-001
Screw-Seal (Meter Register Mounting) 4 503615-001
Lockwasher 4 510003-006
Seal Wire 1 011853-285
Coupling 1 323372-001
Groove Pin 1 510107-002
