Introduction Available Parts

• Pulser Capacity: 0 - 1000 rpm (0-1667 Hz)

• Temperature compensation range: -40 to +158°F (-40 to +70°C)

• Communication between Display Head and IB: RS-485; 2-wire half duplex; custom protocol; 115,200

baud; 8 bit; no parity; 1 stop bit

• Communication between Printer and IB: RS-232; 9600 baud; 8 bit; no parity; 1 stop bit

• Display Head Operating temperature range: -40 to +140°F (-40 to +60°C)

• IB Operating temperature range: -13 to +104°F (-25 to +40°C)

• Display Head and IB Storage temperature range: -40 to +185°F (-40 to +85°C)

• Printer power: +24 Vdc, 2 A (supplied by the IB)

• Printer Operating temperature range: +32 to +122°F (0 to +50°C)

• Printer Storage temperature range: +32 to +122°F (0 to +50°C)

• Weights and Measures: Designed to meet NIST, OIML, Australian and Canadian W&M specifications.

• Relay Ratings: 5A at 120 Vac, 2.5A at 240Vac, 5A at 24 Vdc

• Vibration: MIL-STD-810G, Method 514.6; Table 514.6 C-VI Category 4

• Shock: MIL-STD-810G, Method 516.6; 20G, 11ms, 1/2-Sine

Available Parts

All available EMR4 system parts, including options, are listed below.

• Display Head (P/N 84559X-XXX) - standard

• Keypad Group (P/N 845900-014) - optional

• Bracket with internal V-R Encoder Installation Kit (P/N 845900-015) - included with Display Head

• C&C Corner Switch Group, Normally Open (P/N 845900-018) - included with Display Head

• Slip Printer Kit (10 feet [3.04m] cable included) (P/N 845900-020) - optional

• Temp Probe Kit (P/N 845900-002) - replacement

• Thermowell group - UL/cUL Listed, 350 psi working pressure, Canadian W&M Approved (P/N 0331373-001)

• Interconnect Box (P/N 8457XX-XXX) - standard

• Display Head Hookup Cable: 4-conductor cable from 6 to 1000 feet (1.83 to 152.4 m) lengths (P/N 846000-

1XX)

• Emergency Stop Switch (ESS) Kit (P/N 845900-021) - optional

• Remote Display Head (P/N 84559X-002) - optional

• Remote Display Bracket Install Kit (P/N 845900-024) - optional

• RS-232 Cable Kit (P/N 330020-432 [10 feet {3.04 m}]) - optional

• Top Mount Remote Pulser Kit (P/N 845900-504) - optional

• Front Mount Remote Pulser Kit (P/N 845900-505, 845900-506) - optional

• Epson TM-U220A Roll Printer Only (Cable in separate kit) (P/N 845900-067)

• Printer Cable Kit - 10 feet (3.04 m) (845900-013) - optional

• Printer Cable Kit - 35 feet (10.67m) (845900-071) - optional
