Veeder-Root EMR4 Application Guide

EMR4 Inhibitors - Provisions for Sealing Electronic
58
Figure 44. Display Head Sealing
Figure 45. IB Sealing
Sealing wire
Bottom plate
of Display Head
C&C switch
C&C bolt
Seal
Use the two drilled
through corner bolts,
located in the rear
of housing for sealing
wire.
Sealing wire
Seal
IB cover and bottom sealing wire holes
758-39.eps
