Internet Protocol (H.450) 126
SBX IP 320 Features & Operation Guide
AT SYSTEM B
Operation
To enable the networking feature:
The PGM 320 - FLEX 1 must be set to ON at each System (if the networking lock-key is
not installed, this ADMIN program cannot be enabled).
To satisfy the UDP condition:
Flexible Station Numbering Plan (PGM 105) must be programmed at each System. At
this ADMIN program, the Station number range of System A can be changed from 100 to
199 (100-199), and System B also can be changed from 200 to 299 (200-299).
Note: The changed Station numbers must not conflict with the flexible numbering plan code
for each System.
If system A has a flexible numbering code 2 as its Pick-Up code, then Station numbers that start
with the digit 2, cannot be used.
The destination IP address is needed to route:
PGM 324 - FLEX 4 is used to set the IP address of the destination System's VOIB.
Configure the VOIP Networking between System A & B as listed:
At system A: Enter PGM 105 + [SPEED] + 100 + 199 + [HOLD]
At system B: Enter PGM 105 + [SPEED] + 200 + 299 + [HOLD]
PGM BIN FLEX ITEM VALUE
1 System usage NET (0)
00 2 Numbering plan code 2#**
3 Numbering plan CO group 00
324 4 VOIP Called Party Information 1/2/3/4 0.0.0.0
1 System usage NET (0)
01 2 Numbering plan code 1**
3 Numbering plan CO group 01
4 VOIP CPN Information 1/2/3/4 (note) VOIB IP Address of
system A
To Next Page
