Vertiv Avocent User Manual

Figure 4.1 Web UI
ITEM DESCRIPTION
1
Title bar - Use the title bar to access the online help, log out or
change the current user's password.
2
Tab bar - Use the tab bar to display and manage targets, sensors,
events, administration and alerts.
3
Sidebar - The sidebar is used to display windows that specify
settings or perform operations. The contents of the sidebar vary,
depending on the tab bar and the window that is displayed.
4
Content area - The information specified by the tab bar, title bar
and sidebar selections is displayed and changed in the content
area.
Table 4.1 Web UI Descriptions
4.2 Using the Sidebar
The sidebar is used to display windows that specify settings or perform operations. The contents of the sidebar varies,
depending on the tab and top navigation bar selections and the window that is displayed.
4.2.1 Admin role
By default, Admins have access to all the tabs of the web UI. Admins can access the Targets, Sensors, Events and
Administration tabs of the UI.
By default, the login and password for Admins is admin.
4.2.2 Operator role
Operators can access the Targets, Sensors and Events tabs of the UI.
By default, the login and password for Operators is operator.
4.2.3 User role
Users can access the Targets and Sensor tabs of the UI.
By default, the login and password for Users is user.
Vertiv | Avocent® Universal Management Gateway Appliance Installer/User Guide | 20

Vertiv Avocent Specifications

General

Ports	4
Network Interfaces	2 x 10/100/1000Base-T Ethernet
Management	Web-based, CLI
Remote Access	IP
Authentication	Local, LDAP, RADIUS, TACACS+
Encryption	AES
Operating Temperature	32 to 104°F (0 to 40°C)
