ITEM DESCRIPTION ITEM DESCRIPTION
1 Power supplies 11 DSView server
2 Ethernet connection 12 Remote authentication
3 User 13 PCclient
4 External sensors connection 14 USB media
5 Autosensing ports for serial or service processor targets 15 RJ45 serial setup port
6 UMIQ modulefor KVMconnection 16 DB9 com port
7 Target server (VGA/USB) 17 PCfor local configuration
8 Firewall 18 USBconnection (keyboard, mouse or media)
9 Ethernet connection 19 VGAconsole port
10 Local Area Network (LAN) 20 LCDtray for local configuration and access
Table 2.3 Typical Avocent® Universal Management Gateway Appliance Configuration Descriptions
2.7.1 Using Telnet or SSH to access a serial target
An authorized user can use a Telnet or SSH client to make a connection directly to the console of a serial target if all of the
following are true.
The Telnet or SSH:
• protocol is enabled for network service in the security profile
• protocol is configured for the port
• client is available, and it is enabled on the computer from which the connection is made
To use Telnet to connect to a target through a serial port:
For this procedure, you need the username configured to access the serial port, the target name (for example, 14-35-60-p-1),
device name (for example, ttyS1), TCP port alias (for example, 7001) and the hostname of the appliance or its IP address.
To use a Telnet client, enter the information in the dialog boxes of the client.
-or-
To use Telnet in a shell, enter the following command:
# telnet [ hostname | IP_address ]
login: [username]:[targetname | device_name]
-or-
# telnet [hostname | IP_address] TCP_Port_Alias
login: [username]
To close a Telnet session:
Enter the Telnet hotkey defined for the client. The default is Ctrl + q to quit.
To use SSH to connect to a target through a serial port:
For this procedure, you need the username configured to access the serial port, the target name (for example, 14-35-60-p-1),
TCP port alias (for example, 7001), device name (for example, ttyS1), and the hostname of the appliance or IP address.
To use an SSH client, enter the information in the dialog boxes of the client.
-or-
To use SSH in a shell, enter the following command:
Vertiv | Avocent® Universal Management Gateway Appliance Installer/User Guide | 12

Vertiv Avocent Specifications

General

Ports	4
Network Interfaces	2 x 10/100/1000Base-T Ethernet
Management	Web-based, CLI
Remote Access	IP
Authentication	Local, LDAP, RADIUS, TACACS+
Encryption	AES
Operating Temperature	32 to 104°F (0 to 40°C)
