Appendix K: Video Resolution
The following table lists the video resolutions supported in the UMIQ module's EDID.
VIDEO
RESOL UTION
STANDARD WIDESCREEN
STANDARD
1024 X 768
STANDARD
1280 X 1024
STANDARD
1600 X 1200
WIDESCREEN
1280 X 800
WIDESCREEN
1680 X 1050
WIDESCREEN
1920 X 1080
640 x 400 @60 Hz x x x x x x x
640 x 480 @60 Hz x x x x x x x
640 480 @67 Hz x x x x x x x
640 x 480 @72 Hz x x x x x x x
640 x 480 @75 Hz x x x x x x x
704 x 528 @60 Hz x x x x x x x
704 x 528 @72 Hz x x x x x x x
720 x 400 @70 Hz x x x x x x x
720 x 400 @88 Hz x x x x x x x
720 x 480 @60 Hz x x x x x x x
768 x 576 @60 Hz x x x x x x x
768 x 576 @72 Hz x x x x x x x
800 x 500 @60 Hz x x x x x x x
800 x 600 @56 Hz x x x x x x x
800 x 600 @60 Hz x x x x x x x
800 x 600 @72 Hz x x x x x x x
800 x 600 @ 75 Hz x x x x x x x
832 x 624 @75 Hz x x x x x x x
853 x 480 @60 Hz x x x x x x x
896 x 672 @60 Hz x x x x x x x
896 x 672 @75 Hz x x x x x x x
896 x 672 @85 Hz x x x x x x x
960 x 720 @60 Hz x x x x x x x
960 x 720 @75 Hz x x x x x x x
960 x 720 @85 Hz x x x x x x x
1024 x 640 @60 Hz x x x x x x x
1024 x 640 @75 Hz x x x x x x x
1024 x 768 @60 Hz x* x x* x* x* x x
1024 x 768 @70 Hz x x x x x x x
1024 x 768 @75 Hz x x x x x x x
1024 x 768 @85 Hz x x x x x x x
1024 x 768 @87 Hz x x x x x x x
1152 x 864 @60 Hz x x x x x x
Table K.1 Supported Video Resolution
Vertiv | Avocent® Universal Management Gateway Appliance Installer/User Guide | 108

Vertiv Avocent Specifications

General

Ports	4
Network Interfaces	2 x 10/100/1000Base-T Ethernet
Management	Web-based, CLI
Remote Access	IP
Authentication	Local, LDAP, RADIUS, TACACS+
Encryption	AES
Operating Temperature	32 to 104°F (0 to 40°C)
