Vertiv Avocent User Manual

COLUMN PARAMETER
Translated Source eth0
Translated
Destination
any
Translated Service
Name of the service definition. Example:srv-
SNMP-Traps
Rule State Active
6. From the Policy tab, create a firewall policy with the following settings:
COLUMN PARAMETER
Action Accept
Rule State Active
Destination any
Interface any
Direction Forward
Order Lowest unused number. Example:53
Source Name of network definition. Example:PrivNet
Connection Status Not needed
Table J.3 Firewall Policy Parameters
7. Click Apply when done.
8. From the SP, test sending traps and validate the successful configuration.
Vertiv | Avocent® Universal Management Gateway Appliance Installer/User Guide | 107

Vertiv Avocent Specifications

General

Ports	4
Network Interfaces	2 x 10/100/1000Base-T Ethernet
Management	Web-based, CLI
Remote Access	IP
Authentication	Local, LDAP, RADIUS, TACACS+
Encryption	AES
Operating Temperature	32 to 104°F (0 to 40°C)
