Vertiv Avocent User Manual

NOTE: Changes to the network mode should be performed before targets are configured. Changing the network mode
after adding and configuring targets may interrupt their communication, and they may need to be added again and
reconfigured in order to work again.
3. Click the entry for the desired interface in the table and change the method to Static.
4. Assign the desired IPvalues and click Apply.
3.4 Setting Up Your Network
The appliance uses IP addresses to uniquely identify itself to IP-based target devices. It supports both Dynamic Host
Configuration Protocol (DHCP) and static IP addressing.
As a network infrastructure device, its IPs should be static or use DHCPreservations to ensure the appliance is always
available via a consistent address. GB1 (eth0) on the appliance is a DHCP client intended only to facilitate initial network
access but should be made static before being put into production environments.
An IP address can be obtained via DHCP or a static IP can be assigned using the VGA console or CLI Setup port.
NOTE: If using DHCP, you must first find the IP address assigned to the appliance by looking at the DHCP leases on
the network DHCP server. Enter https://<appliance IP> in your browser to connect to the appliance.
To assign the IP address:
1. Log in to the appliance via its consoleport using admin as both the username and password.
2. Click the Administration button.
3. Click the Network Settings folder.
4. Click the GB1 (eth0) entry in the table and change the method to Static.
5. Assign the desired IP values and click Apply.
3.5 Firewall
Consult the following table to configure access to the appliance through a firewall.
PORT TYPE SERVICE DEFINITION
0 ICMP - Ping srv-PING
20 FTP - Firmware Update srv-FTP-Data
21 FTP - Firmware Update srv-FTP-Commands
22 Encrypted Serial Session srv-SSH-Serial-Session
23 Telnet Session srv-Telnet-Session
69 TFTP srv-TFTP-Services
161 SNMP Set/Get srv-SNMP
162 SNMPTraps srv-SNMP-Traps
443 Encrypted Web UI Access srvWEB-UI
502 Trellis ™ Platform (Modbus Communication) srv-Modbus
514 External Syslog srv-External-syslog
623 Serial over LAN and IPMI NA
843 Web UI Data - Flash srv-Adboe-Flex
1078 DSView™ Proxy Port (Default) srv-DS-View-proxy
2068 Encrypted KVM Session srv-KVM-session
3211 DSView™ Discovery (UDP) srv-Discovery-protocol
Table 3.3 Default Firewall Service Definitions
Vertiv | Avocent® Universal Management Gateway Appliance Installer/User Guide | 16

Vertiv Avocent Specifications

General

Ports	4
Network Interfaces	2 x 10/100/1000Base-T Ethernet
Management	Web-based, CLI
Remote Access	IP
Authentication	Local, LDAP, RADIUS, TACACS+
Encryption	AES
Operating Temperature	32 to 104°F (0 to 40°C)
