Figure 3.3 Example of EBCs Connected to the 8/10 K UPS
Item Description
1 EBC-detection dry contact port. See Table 3.3 on page39, for details.
2 EBC connector
3 EBC-detection port
4 EBC
5 EBC
3 Installation Proprietary and Confidential ©2024 Vertiv Group Corp. 35
Vertiv™ Liebert® GXT5 UPS Installer/User Guide
