11.9.1 Diagnostics—Digital Output Options
Alarm Relay
Enables/disables alarms during manual/diagnostic mode.
K11 Relay
Enables/disables warnings during manual/diagnostic mode.
Q15 Output State
Enables/disables Q15 output during manual/diagnostic mode.
11.10 Diagnosing Analog Output Issues
1. Touch , then > Diagnostic/Service > Diagnostics > Analog Outputs in the Category list. The ANALOG
OUTPUTS panel displays.
2. Refer to Diagnostics—Analog Output Options below , for descriptions of diagnostic options.
NOTE: Depending on the type of thermal management unit, included components, and control settings of your system,
all of the options listed may not be available on your iCOM™ display.
11.10.1 Diagnostics—Analog Output Options
Analog Output N
Controls analog outputs during manual/diagnostic mode. (Where N is the analog output number.)
11.11 Diagnosing Customer Input Issues
1. Touch , then > Diagnostic/Service > Diagnostics > Customer Inputs in the Category list. The
CUSTOMER INPUTS panel displays.
2. Refer to Diagnostics—Customer Input Options below , for descriptions of diagnostic options.
NOTE: Depending on the type of thermal management unit, included components, and control settings of your system,
all of the options listed may not be available on your Vertiv™ Liebert® iCOM™ display.
11.11.1 Diagnostics—Customer Input Options
Input N
Status and description of customer-input sensors. (Where N is the input number.)
