SNMP Trap Port
Port used by the target host for receiving notifications; default is 162.
SNMP Trap Community String
String identifying a secret known only by those hosts that want to be notified of device status changes.
Configuring SNMPv1/v2c Access
Unity supports up to 20 network hosts that access data using SNMPv1/v2c. The top level is a list of all 20.
1. Touch , then > BMS & Teamwork > IS-Unity  Setup > Protocols > SNMP> SNMPv1v2c Access, then
one of the listed access options.
2. Enter the information and set the permissions appropriate to the network host, and touch Save.
3. Repeat steps 1 and 2 for additional users.
4. Restart Unity:
a. Touch , then > BMS & Teamwork > IS-Unity  Settings.
b. Touch Restart IS-Unity., then touch Yes.
SNMPv1/v2c Access Settings
SNMP Access IP Address
Configure network hosts interested in device information access. The host can be identified as either an IP address or
the host’s network name.
SNMP Access Type
SNMPv1/v2C access type: Read-only or Read/Write.
SNMP Access Community String
SNMP Community String.
8.3 Unity Status Readings
The read-only Status page displays the system status of IS-Unity and a list of events that affect its status.
To view the statuses, touch , then > BMS & Teamwork > IS-Unity  Setup > Status.
