Temperature Setpoint Act
Read-only display of adjusted temperature setpoint when one of the following is active:
• Temperature compensation
• BMS backup temperature setpoint
• Customer input setpoint (remote alarm device)
Temperature Setpoint
Temperature that the unit maintains via cooling/reheat.
2.2 Viewing Unit Alarms
The ALARMS panel lists active alarm and warning events. Table 2.1 below describes the type and state of the alarm shown
by indicator dots.
Indicator Description
Yellow dot Warning event.
Red dot Alarm event.
Circle Event condition has cleared, but still must be acknowledged. See Acknowledging Alarms on the next page .
Table 2.1 Alarm Status and Type Indicators
2.2.1 To View Alarms
1. Touch , then > Alarms. The ALARMS panel opens.
2. Touch an alarm to display the ALARM DETAILS panel.
Alarm Fields
Alarm
Name of the event.
Date
Date event was logged.
Time
Time event was logged
2 User Operation
17
Vertiv™ Liebert® iCOM™Installer/User Guide
