Vertiv | Liebert PEX+ Chilled Water | User Manual 29
Installation
No. Description No. Description
1 6-Ø14 hole 3 Bottom rubber cushion
2 Bottom rubber cushion, 6PCS
Figure 2-19 Mounting Floor Stand of Two Bay Series
No. Description No. Description
1 8-Ø14 hole 3 Bottom rubber cushion
2 Bottom rubber cushion, 4PCS
Figure 2-20 Mounting Floor Stand of Three Bay Series
