Vertiv | Liebert PEX+Chilled Water | User Manual 30
Installation
Table 2-6 Mounting Floor Stand Dimensions (inch/mm)
Model A B C D E M F H W
P1030 - P1060 810 860 / 980 930 /
/ 400 <H≤550 40
F≤240 550 <H≤1100 50
P2070 - P2100 1560 860 735 980 1680 /
/ 400 <H≤550 40
F≤240 550 <H≤1100 50
P2110 ~ P2140 1710 860 810 980 1830 /
/ 400 <H≤550 40
F≤240 550 <H≤1100 50
P3150 2385 860 735 980 2505 825
/ 400 <H≤550 40
F≤240 550 <H≤1100 50
P2090 ~ P2100 2610 860 810 980 2730 900
/ 400 <H≤550 40
F≤240 550 <H≤1100 50
• Refer to Table 2-7 A/B/C/M as the center of the base from the mounting hole D/ E is the size of the base
frame and front door will 15 mm above the mounting base.
• H is the height of the base, F is the distance between the joint angle steel and the floor.
• W is the width of the angle iron, it is recommended to use size of the angles 40 mm x 40 mm x 3 mm or
50 mm x 50 mm x 4 mm specification.
• For the downflow unit, the base must be greater than the height of 400 mm.
• For the upflow unit, the base height must be about 200 mm.
• The side panels are suspended to the frame of the unit, ensure that floor stand should bear the weight of
the panels.
• The distance between the obstacles that may obstruct the air supply around the upper edge of the base
and the outer edge of the EC fan shall be greater than 160 mm.
• Installing Floor Stand
Procedure to install floor stand for Liebert PEX+CW:
1. Determine the installation position according to the space requirements of the unit, and fix the floor stand
onto the selected mounting position.
2. Rigidly fix the floor stand to the ground using expansion bolts or spot welding, and ensure the alignment of the
floor stand is calibrated by a horizontal ruler before it is fixed.
3. Ensure that the top surface of floor stand is at uniform level.
While designing and installing the downflow unit which requires lowering of EC fan, installation team must
consider the proper gap distance and the base strength of the floor stand.
