Vertiv | Liebert PEX+ Chilled Water | User Manual 37
Installation
No. Description No. Description
1 L-shaped beam 4 Winch handle
2 Fan 5 Fixing bolt
3 Winch
Figure 2-27 Installed Winch Bracket
No. Description
1 Bolt
Figure 2-28 Position of Fixing Bolt
5. Install the fixing bolts, as shown in Figure 2-28 and hold the arrangement tight during operation with total four
PCS of bolts.
