Vertiv | Liebert PEX+ Chilled Water | User Manual 42
Electrical Installation
No. Description
1 Cable clamp
Figure 3-1 Location of Electrical Control Box (Upflow unit)
No. Description
1 Cable clamp
Figure 3-2 Location of Electrical Control Box (Downflow unit)
