Topics in this section include:
Menus and Navigation
Whether working on the set or in the
eld, time is precious, and monitoring
live recordings often requires quick
adjustments in fast-paced workows.
The PIX-E5 and PIX-E5H feature an
on-screen display (OSD)and menus
in an easy to navigate structure, with
many options readily accessible via the
touch screen or multi-functional soft key
buttons.
The Main menu is one press of a button
away with easy navigation via the
Control knob or touch screen.
Touch Screen and Tactile Controls
Whether you want the quick efciency of a touch-screen interface or prefer the
tactile feedback of real buttons and want to keep the monitor’s screen free of
ngerprints, the PIX-E monitors offer a “best of both worlds” approach to user
controls.
All PIX-E LCDs are touch-screen enabled, but the monitors also feature tactile
buttons and a Control knob. Use the buttons to turn on or off monitor functions.
Elements of menus and dialogs may be selected or adjusted by touching the
screen or by using the Control knob, so you have the choice when it comes to
navigating through the user interface.
While directions throughout this guide describe how to use the Control knob for
navigation, touching the screen is often a quicker alternative.
Accessing the MAIN MENU Screen
The MAIN MENU screen displays an easy-to-navigate menu, organized with sub-
menus, options, and parameters.
To access the MAIN MENU screen:
X Press the MENU button.
Touch Screen and Tactile Controls
Accessing the MAIN MENU Screen
Toggling On-Screen Display Elements
Toggling Soft Key Button Functionality
Monitor Soft Keys
Record Soft Keys
Using Soft Key Menus
Configuring the On-Screen Display
USB Keyboard
