MENUS AND NAVIGATION
setting Description options
See-Thru Use this setting to adjust the opacity of soft key menus and
the information bar by increments of 25%. Set to 0% for fully
opaque and 100% for full transparency. This setting does not
affect the soft key labels, which are superimposed with a fully
transparent background. The default is 50%.
0 to 100%
Brightness Use this setting to adjust the brightness of the display image
by increments of 1%. The default is 0%.
-20 to 20%
Contrast Use this setting to adjust the contrast of the display image by
increments of 1%. The default is 100%.
0 to 200%
Chroma Use this setting to adjust the chroma level of the display im-
age by increments of 1%. The default is 100%.
0 to 200%
Backlight Use this setting to adjust the backlight level of the LCD by
increments of 5%. The default is 70%.
0 to 100%
i The Monitor menu also provides settings for adjusting headphone source and lev-
els. For more information, see Routing Audio Output.
USB Keyboard
PIX-E monitors support the use of a standard USB keyboard connected to the
USB A connector on the right panel of the chassis. The keyboard may be used
to navigate menus, enter text, and perform various other functions.
context Key action
All
Shift ALT button
M, F12 MENU button
F1-F12
Soft Key buttons. F1 is the rst button to the right of the
ALT button, F2 is the next button to the Right, etc.
CTRL + R Record
Space Play/Pause
CTRL + S Stop
Esc Cancel / Go back
Live View Enter Enable TapZoom
Zoom mode
Enter Switch between horizontal and vertical positioning.
Up/Down arrow Reposition center point
Alt + Enter Exit TapZoom
Audio screen &
File screen
Up arrow Move up one track or le
Down arrow Move down one track or le
Enter Select track or le
Esc Exit to main screen
Audio screen
with track se-
lected
Up arrow Move one eld to the right
Right arrow Move one eld to the right
Down arrow Move one eld to the left
Left arrow Move one eld to the left
Enter Select eld for editing
