AUDIO
options on the pix-e5 options on the pix-e5h
Line In 1 Line In 1
Line In 2 Line In 2
XLR 1
*
XLR 1
*
XLR 2
*
XLR 2
*
SDI In 1 / HDMI In 1 HDMI In 1
SDI In 2 / HDMI In 2 HDMI In 2
SDI In 3 / HDMI In 3 HDMI In 3
SDI In 4 / HDMI In 4 HDMI In 4
SDI In 5 / HDMI In Off Off
SDI In 6 / HDMI In Off
SDI In 7 / HDMI In Off
SDI In 8 / HDMI In Off
Off
* Applies only if PIX-LR accessory is attached
Setting up Tracks
The Audio screen provides the ability to customize track names, set gain levels,
adjust input delays, and arm or disarm certain tracks. Use an input delay to
align audio with delayed video output from cameras.
To arm or disarm a track:
1. From the Audio screen, select the track to adjust.
2. Turn the Control knob to highlight the track’s number eld.
3. Press the Control knob to select option to either arm or disarm the track.
i Additional options include arming or disarming all tracks.
To edit a tracks’ name:
1. From the Audio screen, select the track to adjust.
2. Turn and press the Control knob to edit the track’s name eld.
3. Use the on-screen keyboard, or attached USB keyboard, to enter the track’s
new name.
4. Select OK, or press Enter on a USB keyboard, if attached.
To adjust a track’s input gain:
1. From the Audio screen, select the track to adjust.
2. Turn and press the Control knob to select the track’s Gain eld.
3. Adjust the gain in +/- 1 dB increments from -40 dB to +20 dB as needed.
The default is 0 dB.
4. Press the Control knob to exit adjustment mode.
