To adjust a track’s input delay:
1. From the Audio screen, select the track to adjust.
2. Turn and press the Control knob to select the input delay eld.
3. Adjust the input delay in millisecond intervals.
4. Press the Control knob to exit adjustment mode.
Routing Audio Output
Audio tracks 1 through 8 are embedded in SDI and HDMI outputs.
The PIX-E5H outputs audio to its HDMI output. The PIX-E5 outputs audio to
both SDI and HDMI outputs.
The monitor also features a 3.5 mm headphone output. The audio source for
this output is user-denable.
To choose a headphone source:
1. Press and hold the MENU button for 1 second to access the Monitor menu.
2. Select the HP Source tab.
3. Select a headphone source.
source Description
1,2 Select this stereo option for routing channel 1 to the left and 2 to the right.
3,4 Select this stereo option for routing channel 3 to the left and 4 to the right.
5,6 Select this stereo option for routing channel 5 to the left and 6 to the right.
7,8 Select this stereo option for routing channel 7 to the left and 8 to the right.
1357,2468 Select this stereo option for routing odd channels to the left and even
channels to the right.
12345678 Select this mono option if you want all audio inputs routed to both sides of
headphones.
To adjust headphone gain:
i As a safety precaution, the touch screen is disabled to avoid sudden, acciden-
tal changes to headphone gain. Adjustments can only be made using the Control
knob.
1. Press and hold the MENU button for 1 second to access the Monitor menu.
2. Select the HP Gain tab.
3. Adjust the HP gain, using the Control knob.
